Spray Head Valve Body, 3" Integral Sprayhead Valve, UnitedBuilt BC2410B - UnitedBuilt Equipment

BC2410 Spray Head Valve Body, A356-T6 Aluminum, UnitedBuilt BC2410B

SKU 0007226
Brand UnitedBuilt
Availability:
75 in stock | Available on backorder
$0.00 - $0.00
$0.00
$136.00
$136.00 - $136.00
$136.00

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The UnitedBuilt BC2410B is the replacement body for the BC2410 integrated spray head valve. Its sand-cast A356 aluminum construction is heat-treated to T6, and the body is manufactured in the USA.

The body connects to 3-inch grooved plumbing and forms the housing for the valve and spray outlet. It is a body-only service part, not a complete air-operated spray head. Replacing the housing requires checking the condition and suitability of the remaining valve components.

Technical specifications

Specification Details
Part number BC2410B
Body material Sand-cast A356-T6 aluminum
Connection 3-inch grooved
Body manufacture USA

Applications and related parts

Selection Details
Valve application UnitedBuilt BC2410, normally closed and air-to-open
Spray adjustment Use with the correct BC2410 adjustable spray band
Other selections Cap, clamp, band and internal seal assembly are separate components

Before ordering

Check What to confirm
Housing match Confirm the BC2410 model and compare the existing body before ordering.
Repair scope Check sealing areas and related parts; a body does not replace a damaged diaphragm or spring.
Safe service Isolate water and control air, release trapped pressure and follow the valve service procedure before disassembly.

Need help selecting the correct replacement? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your valve model, plumbing connection and body photos.
