4000 Gallon Water Truck, 2025 Kenworth T480, Allison 3500-RDS, 60K GVWR

Truck Specifications
Manufacturer
Kenworth
Year
2025
Model
T480
Front Axle
20,000 lbs
Rear Axle
40,000 lbs
Transmission Make
Allison
Transmission Model
3500-RDS
Tansmission Type
Automatic
Transmission Speed
6 Speed
Engine Make
Paccar
Engine Model
PX-9
Horsepower
300 HP
Locking Differential
Yes
Tank Specifications
Tank Model
6V15
Tank Length
15'
Capacity
4,000 Gallons
Tank Series
Vision Tank (Modified Trapezoid)
Tank Profile
6V
Product Type
Water Truck

Product Images

Images are for representation only and may differ from the actual product.

Request a quote

** (9) AVAILABLE TO PRE-ORDER - SCHEDULED PRODUCTION Q2-Q3 2024**

UnitedBuilt WT4000 6-Valve Water Truck

NEW Kenworth T480, PX-9 300HP, Allison 3500-RDS Automatic Transmission

New Kenworth Factory Warranty.

** NOTE: Pictures show T370 - T480 model pictures pending **

** NOTE: Pictures may be shown with optional upgrades such as Water Cannon, Suction FIll, Hose Reel & High-Pressure Pump. These are available as options.

**WATER TRUCK TANK & SPRAY SYSTEM SPECS:

NEW UnitedBuilt WT4000 Vision Tank with 6 Independent Air Operated Cab Controlled Spray Heads.

  • WATER TRUCK MODEL: WT4000
  • TANK MODEL: 6V15
  • TANK SERIES: Vision Tank (VT)
  • TANK LENGTH: 15'
  • CAPACITY: 4000 Gallons
  • SHELL: Premium Quality 3/16" ASTM A36 Sheet Steel
  • BAFFLE: 2 Fitted & Welded both Sides 100%; 1/4" Heads
  • BELLY PLATE: Full Length Reinforcement Preventing Premature Cracking and Deterioration Premium Quality 3/16" ASTM A36 Sheet Steel
  • LADDER: Rear Mount; 3/4" Construction
  • MANWAY: 25" Diameter Round Manway w/ Hinged Non-Sealing Lid
  • NON-SLIP: Non-slip Catwalk to Manway
  • HYDRANT FILL: 2-1/2" Swiveling Hydrant Fill w/ Air Gap
  • SIGHT GAUGE: Front & Rear
  • FENDERS: 12 Gauge Steel Construction
  • REAR BUMPER: Push Plate Bumper 1/2" Construction w/ Storage Bedliner Coated
  • LIGHTS: Standard DOT Specs LED; Wiring in Conduit
  • BU ALARM: Peterson 780
  • PAINT: Tank Exterior Powder Coated White to Match Cab with Zinc Base Layer for Enhanced Corrosion Resistance
  • PUMP: UnitedBuilt Cast Iron 4X3 *CW* Centrifugal w/ Mechanical Seal
  • DRIVE: *Hot* Shift PTO; Balanced 1710 Series Tube PTO Shaft
  • FRONT SPRAY: (2) UnitedBuilt 3" AV1100 Air Operated Valves with (2) 3" UnitedBuilt BC2399 Adjustable Spray Heads
  • MIDSHIP SPRAY: (2) UnitedBuilt 3" AV1100 Air Operated Valves with (2) 3" UnitedBuilt BC2179 Side Sprays
  • REAR SPRAY: (2) UnitedBuilt 3" AV1100 Air Operated Valves with (2) 3" UnitedBuilt BC2399 Adjustable Spray Heads
  • TANK WARRANTY: 5-Year Tank Construction per UTE Limited Warranty
  • PLUMBING WARRANTY: 1-Year Plumbing Warranty per UTE Limited Warranty

POPULAR WATER TRUCK UPGRADES:

  • Elkhart Water Cannon (Electric or Manual)
  • 50’ to 100' Hose Reel (Manual, Electric, Hydraulic or Spring Rewind)
  • Self Loading Suction Fill
  • Gravity or Pressure Bar
  • Articulated Spray Heads
  • Additional Spray Heads
  • Flusher Spray Heads
  • Interior Epoxy Coat

TRUCK SPECS:

NEW Kenworth T480

  • MAKE: Kenworth
  • MODEL: T480
  • ENGINE: Paccar PX-9 300HP Diesel Engine with Exhaust Brake
  • TRANSMISSION: Allison Automatic 3500-RDS
  • FRONT AXLE: 20000# Front Axle, Taperleaf with Shock Absorbers
  • REAR END: 40000# Rear Axle
  • CROSS LOCKERS: Full Cross Lockers on Rear Tandem
  • REAR SUSPENSION: Tandem Hendrickson Haulmaax EX (HMX) 400
  • WHEELS/TIRES FRONT: (2) 315/80R22.5 20PR, Bridgestone M870 with Accuride 29039 Steel Powder Coated White
  • WHEELS/TIRES REAR: (8) 11R22.5 14PR, Bridgestone M843 with Accuride 50344 Steel Wheels Powder Coated White
  • SAFETY: Warning Triangle Reflector Kit, 5# Fire Extinguisher
  • FEATURES: Air Ride Seat, A/C, AM/FM/WB Radio, Cruise Control, Telescoping/Tilting Steering Column, CB Antenna & Wiring, Electric Door Locks, Bendix Air Dryer
  • WARRANTY: New Kenworth Factory Warranty
