O-Ring, AS-568-152 3.237 x.103, Elkhart 57414000 - UnitedBuilt Equipment

O-Ring, AS-568-152, 3.237 x 0.103 in., Elkhart 57414000

SKU 0012759
Brand Elkhart Brass
Availability:
0 in stock. Available on backorder
Save 19% Save 19%
$19.00
$19.00 - $19.00
$19.00
$15.40
$15.40 - $15.40
$15.40

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The Elkhart Brass 57414000 O-ring is a replacement sealing component for IMS-750 and IMS-1000 master-stream nozzles. Its AS-568-152 size measures 3.237 inches inside diameter with a 0.103-inch cross-section, helping you distinguish it from other O-rings used in the same equipment.

Choose this part when the nozzle service parts list calls for 57414000. It is an individual O-ring component, not a complete nozzle or a multi-piece seal kit; match the exact part number and installed nozzle model before ordering.

Replace the correct nozzle seal

Servicing the specified O-ring lets you address that sealing component without ordering a complete nozzle. Check the surrounding sealing surfaces and the other seals during service so a damaged mating part is not overlooked.

Feature Benefit
Exact replacement part number Helps avoid substituting a similar-looking seal from another position in the nozzle.
Defined O-ring dimensions Supports comparison with the specified replacement size when planning maintenance.

Technical specifications and fitment

Specification Detail
Manufacturer Elkhart Brass
Part number 57414000
Size designation AS-568-152
Inside diameter 3.237 inches
Cross-section 0.103 inch
Nozzle application IMS-750 and IMS-1000
Product supplied O-ring component; not a nozzle or full seal kit

Before ordering

Do not select a substitute by approximate diameter alone. Confirm the service part number for your equipment and follow its installation and lubrication instructions. Inspect the assembled nozzle and verify correct operation before returning it to service.

Check What to confirm
Nozzle identification Match IMS-750 and IMS-1000 and the specified 57414000 service part.
Seal position Check the parts list: other O-rings in the same nozzle can have different dimensions.
Service requirements Confirm the correct lubricant and installation procedure for the nozzle.
Additional parts Order other seals or damaged components separately as needed.

Need help selecting the correct part? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your nozzle model, existing part number and photos.
