Elkhart SM-10FE(D) 20-120 GPM 2-1/2" FNHT 12V Electric Nozzle - 03817601 - UnitedBuilt Equipment

Elkhart SM-10FE(D) 20-120 GPM 2-1/2" FNHT 12V Electric Cannon Nozzle - 03817601

SKU 0012844
Brand Elkhart Brass
Availability:
0 in stock. Available on backorder
Save 19% Save 19%
$3,754.00
$3,754.00 - $3,754.00
$3,754.00
$3,030.00
$3,030.00 - $3,030.00
$3,030.00

Product Images

Images are for representation only and may differ from the actual product.

The Elkhart SM-10FE(D) 03817601 is a 12V electric automatic-flow cannon nozzle with a 2-1/2-inch female NH/NST inlet and Deutsch electrical connection. It delivers 20–120 GPM and provides powered straight-stream, narrow-fog, and wide-fog pattern control for compatible remote monitors.

Features and Benefits

Feature Benefit
Automatic 20–120 GPM flow range Supports lower-flow water application while maintaining an effective stream pattern.
12V electric actuation Provides remote fog-to-straight-stream control.
Deutsch connector Supports sealed electrical integration with compatible monitor controls.
Manual override Allows local nozzle operation when needed.

Specifications

Specification Details
Manufacturer Elkhart Brass
Model SM-10FE(D)
Manufacturer part number 03817601
Flow range 20–120 GPM
Inlet 2-1/2-inch FNHT (female NH/NST)
Voltage 12V DC
Electrical connection Deutsch
Stream patterns Straight stream, narrow fog, and wide fog

Recommended Monitor Pairings

Monitor Pairing guidance
Sidewinder EXM2 7100SDX2 Recommended pairing when the monitor discharge and control configuration match the nozzle.
Sidewinder EXM2 7100HDX2 Recommended heavy-duty pairing when the monitor discharge and control configuration match the nozzle.

Before Ordering

Check Requirement
Monitor discharge Confirm a matching 2-1/2-inch male NH/NST connection.
Electrical system Confirm 12V DC power and a compatible Deutsch connection.
Controls and harnesses Verify compatibility with the selected monitor and controller configuration.
Available water flow Confirm the pump and plumbing can support the desired operating flow.
