Base, Quick Connect, 2.5" Male NPT to Female Monitor, Elkhart 00007150 - UnitedBuilt Equipment

Monitor Quick-Connect Base, 2.5" FNPT × MNPT, Aluminum, Elkhart 00007150 (7150)

SKU 0012705
Brand Elkhart Brass
Availability:
0 in stock. Available on backorder
Save 19% Save 19%
$1,614.00
$1,614.00 - $1,614.00
$1,614.00
$1,307.00
$1,307.00 - $1,307.00
$1,307.00

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The Elkhart 7150 monitor quick-connect base, part 00007150, provides a removable connection between your water cannon and supply plumbing. Its 2.5" female NPT × 2.5" male NPT ends fit a threaded installation, while the quick-connect coupling lets you remove the monitor for storage or access without unthreading the plumbing each time.

Once installed, the coupling locks and unlocks with a one-third turn. The Elk-O-Lite aluminum assembly includes the mating threaded adapters and locking mechanism; the monitor is sold separately.

Quick removal for access and storage

Feature Practical benefit
Tool-free operation after installation Remove and reconnect the monitor without a wrench.
One-third-turn connection Lock or unlock the monitor with a short rotation.
Pressure safety lock Helps prevent accidental disconnection while the waterway is pressurized.

Technical specifications

Specification Detail
Manufacturer part number 00007150
Model 7150
Connections 2.5" FNPT × 2.5" MNPT
Construction Elk-O-Lite aluminum
Maximum pressure 500 PSI
Weight 2.8 lb

Connections and compatibility

The standard installation places the male NPT adapter in the monitor’s female inlet and the female NPT adapter on the male supply connection. The coupling supports flow in either direction; another arrangement may require additional adapters.

Application Connection or selection
Sidewinder EXM / EXM2 monitor Select the monitor configuration with a matching 2.5" FNPT inlet.
Monitor connection 2.5" male NPT adapter
Supply connection 2.5" female NPT adapter
Additional plumbing adapters Select separately when required by the installation.

Before ordering

Check What to confirm
Thread type Match 2.5" NPT pipe threads on both connections.
System pressure Do not exceed the lowest-rated component in the assembled system.
Installation Use suitable thread sealant and a strap wrench according to Elkhart’s instructions.
Lock engagement Confirm the lock ring snaps securely into its mating notches before applying pressure.
Removal Shut off the water supply and relieve pressure before disconnecting the monitor.

Need help confirming the correct monitor connection? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your monitor model, connection size, and application.
