Elkhart Brass 7010X2 EXM2 J1939 CAN Bus Panel Mount Controller - 02007010

Elkhart Brass 7010X2 EXM2 J1939 CAN Bus Panel Mount Controller - 02007010

SKU 0012846
Brand Elkhart Brass
Availability:
0 in stock. Available on backorder
Save 19% Save 19%
$2,096.00
$2,096.00 - $2,096.00
$2,096.00
$1,698.00
$1,698.00 - $1,698.00
$1,698.00

Product Images

Images are for representation only and may differ from the actual product.

The Elkhart Brass 7010X2 EXM2 Panel Mount Controller, part number 02007010, is a hardwired operator control for Elkhart EXM2 electric monitor systems. Designed for installation in a vehicle or equipment control panel, it connects directly to the EXM2 CANbus network to provide centralized control of the monitor, electric nozzle, and compatible optional accessories.

The 7010X2 provides dedicated controls for UP, DOWN, LEFT, RIGHT, STOW, DEPLOY, and OSCILLATE, along with FOG and STREAM nozzle control. When used with a compatible EXM2 Unibody valve, the panel also supports OPEN, CLOSE, and PRESET valve functions. An AUX control can operate an external device such as a light or camera.

Built for demanding mobile equipment, the controller is IP67 rated and compatible with 12 or 24 VDC systems. Its CANbus architecture simplifies integration into Elkhart EXM2 monitor systems used on water trucks, fire apparatus, industrial water systems, and other remote-controlled water-cannon applications.

Key Features

Feature Details
EXM2 CANbus Control Hardwired controller for compatible Elkhart EXM2 monitor systems
Monitor Movement Controls Dedicated UP, DOWN, LEFT, and RIGHT controls
Automated Monitor Functions Dedicated STOW, DEPLOY, and OSCILLATE controls
Electric Nozzle Control FOG and STREAM controls for compatible electric nozzles
Optional Valve Control OPEN, CLOSE, and PRESET controls for compatible EXM2 Unibody valves
Auxiliary Output Control AUX function can control an external accessory such as a light or camera
12/24 VDC Compatibility Suitable for common mobile-equipment electrical systems
IP67 Rated Sealed for demanding vehicle and outdoor installations

Specifications

Attribute Details
Manufacturer Elkhart Brass
Manufacturer Part Number 02007010
Model 7010X2
Product Type Panel Mount Monitor Controller
System Elkhart EXM2
Communication CANbus / J1939-based EXM2 network
Input Voltage 12 or 24 VDC
Environmental Rating IP67
Mounting Panel Mount
Monitor Controls UP / DOWN / LEFT / RIGHT / STOW / DEPLOY / OSCILLATE
Nozzle Controls FOG / STREAM
Optional Valve Controls OPEN / CLOSE / PRESET
Auxiliary Control AUX output for compatible external accessory

Applications

Application Use Case
EXM2 Monitor Systems Primary panel-mounted operator control for compatible Elkhart EXM2 monitors
Water Truck Cannons Cab or control-panel operation of monitor movement and electric nozzle functions
Construction Water Trucks Remote water-cannon control for dust suppression and road-watering systems
Mining Water Trucks Panel-mounted control for high-duty dust-control monitor systems
Fire & Industrial Apparatus Remote monitor, nozzle, valve, and auxiliary control from an operator station
