Hydraulic Fitting, 90 Degree Elbow, 12 Female JIC x 12 Male JIC, 6500 - 12 - 12 - UnitedBuilt Equipment

UnitedBuilt Choice Hydraulic 90-degree swivel elbow, -12 Male JIC x -12 Female JIC swivel – 6500-12-12

SKU 0012653
Brand UnitedBuilt Choice
Availability:
17 in stock | Available on backorder
$0.00 - $0.00
$0.00
$21.30
$21.30 - $21.30
$21.30

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The UnitedBuilt Choice 6500-12-12 is a 90-degree swivel elbow with -12 Male JIC x -12 Female JIC swivel. Use it to join the specified hydraulic connection types without changing the mating equipment ports.

Compare both the fitting end and its mating connection, including thread form, size and sealing surface. Dash sizes describe nominal connection sizes; they are not the measured outside diameter of the thread. This listing is for the adapter, not a complete hose assembly.

Match the connection to the job

The 90-degree layout changes connection direction at the adapter. Check space around the port and the hose bend radius rather than forcing the hose into a tight bend.

Feature Benefit
Connection-specific design Select by the complete end type and dash-size combination, not by appearance alone.
90-degree swivel elbow Matches the stated connection layout when the port clearance and mating parts are correct.
37-degree flare connection Mates to the matching JIC seat; the threads draw the sealing surfaces together.

Technical specifications

Specification Detail
Brand UnitedBuilt Choice
Part number 6500-12-12
Series 6500
Configuration 90-degree swivel elbow
End 1 Male JIC 37-degree flare; -12 (3/4 inch tube OD)
End 1 thread 1-1/16-12
End 2 Female JIC 37-degree flare swivel; -12 (3/4 inch tube OD)
End 2 thread 1-1/16-12

Before ordering

Confirm the supplied fitting's pressure and temperature limits, material compatibility and suitability for the hydraulic fluid before installation. A series number and dash size do not establish those ratings. Isolate and depressurize the circuit before work, and follow the equipment and fitting supplier's installation procedure.

Check What to confirm
End 1 mating part Corresponding female 37-degree JIC. Metal-to-metal mating 37-degree flare surfaces; the parallel threads provide clamping, not the fluid seal.
End 2 mating part Corresponding male 37-degree JIC. Metal-to-metal mating 37-degree flare surfaces; the parallel threads provide clamping, not the fluid seal.
Inspection Check threads, sealing surfaces and any O-ring for damage or contamination. Do not force an incompatible thread or seat.
Swivel use Use for assembly positioning only unless the supplied fitting is specifically rated for live rotary service.

Need help selecting the correct adapter? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your connection sizes, existing fitting number and application.
