Hydraulic Fitting, 90 Degree Elbow, 16 (1") Female NPTF x 16 (1") Female NPTF, 5504 - 16 - 16 - UnitedBuilt Equipment

UnitedBuilt Choice 90-degree elbow, 1" female NPTF x 1" female NPTF – 5504-16-16

SKU 0012649
Brand UnitedBuilt Choice
Availability:
20 in stock | Available on backorder
$0.00 - $0.00
$0.00
$32.75
$32.75 - $32.75
$32.75

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The UnitedBuilt Choice 5504-16-16 is a 90-degree elbow with 1" female NPTF x 1" female NPTF.

This female-to-female elbow connects two compatible male pipe ends around a 90-degree corner. Both openings are female NPTF, making it a different arrangement from a male-to-female street elbow. Confirm the thread gender and nominal size at each connection before choosing a replacement.

Connect two male pipe ends around a corner

The fixed right-angle body changes the direction of the connection without requiring the connected rigid components to bend. It is useful where the installation already calls for a 90-degree pipe connection. Check room around the elbow and attached parts, including the space needed to turn the components during assembly.

Feature Benefit
Two female pipe connections Receives matching male-threaded fittings on both sides.
90-degree fixed body Changes direction without bending the connected rigid components.

Technical specifications

Specification Detail
Brand UnitedBuilt Choice
Part number 5504-16-16
Series 5504
Configuration 90-degree elbow
End 1 1" female NPTF
End 1 thread 1-11.5
End 2 1" female NPTF
End 2 thread 1-11.5

Before ordering

Plan the assembly sequence so a hose is not twisted and rigid lines are not pulled into alignment by the fitting. Follow the actual fitting supplier’s pipe-thread procedure, including any required sealant or lubricant. Do not loosen a completed tapered joint to point the elbow in a different direction.

Check What to confirm
First connection Use a compatible male tapered pipe fitting of the stated size and pitch.
Second connection Match the second male connection independently; both elbow ends are female NPTF.
Installation space Check the elbow envelope, component clearance and wrench access.
Connection movement Use as a rigid elbow, not an adjustable fitting or live rotary joint.

Confirm the supplied part’s pressure and temperature limits, material compatibility and suitability for the operating fluid before installation. Connection size alone does not establish a service rating. Isolate and fully depressurize the circuit before work, and follow the equipment and fitting supplier’s installation procedure.

Need help selecting this female pipe elbow? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with both male connection sizes, available space and the existing fitting number.
