Sleeve, Spacer, 1 - 3/16" ID x 1 - 3/8" OD, Bearing B3ZRM Pump Shaft, Berkeley S08980 - UnitedBuilt Equipment

Bearing Spacer Sleeve, 1-3/16" ID x 1-3/8" OD, Berkeley S08980

SKU 0000957
Brand Berkeley
Availability:
4 in stock | Available on backorder
Save 35% Save 35%
$91.00
$91.00 - $91.00
$91.00
$58.88
$58.88 - $58.88
$58.88

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The Berkeley S08980 bearing spacer sleeve is a shaft-assembly service component for selected Berkeley pumps. It measures 1-3/16 inches inside diameter by 1-3/8 inches outside diameter and is used in a different position from the sleeve at the pump packing.

For B3ZRM catalog numbers B59539 and B59538, this is the spacer sleeve associated with the bearing arrangement. Identify the part by both its manufacturer number and location rather than ordering a general shaft sleeve with similar dimensions.

Technical specifications

Specification Details
Manufacturer Berkeley
Manufacturer part number S08980
Component Bearing spacer sleeve
Inside diameter 1-3/16 inches
Outside diameter 1-3/8 inches

Compatible configurations

Pump or assembly Selection
B3ZRM, packing construction Catalog B59539 CW or B59538 CCW; item 78
B75298 shaft replacement kit Bearing spacer component, item 78

Before ordering

Check What to confirm
Pump configuration Check the exact B3ZRM catalog number and drive arrangement.
Spacer versus shaft sleeve Confirm the bearing spacer is required, not the separate packing-area shaft sleeve.
Dimensions and placement Compare the removed part and assembly position; diameter alone does not establish fit.

Need help confirming the correct replacement? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your pump catalog number, existing part number, and shaft-assembly photos.
