Elkhart Brass 28146001 7100 EXM Aluminum Discharge Elbow

Name: Elkhart Brass 28146001 7100 EXM Aluminum Discharge Elbow
Brand: Elkhart Brass
SKU: 0012702
Price: 784.0 USD
Availability: InStock

UGC 0012702

par Elkhart Brass

Disponibilité:

0 in stock. En stock

Économisez 19%

$968.00

$968.00 - $968.00

$968.00

$784.00

$784.00 - $784.00

$784.00

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

La description

The Elkhart Brass 28146001 is an aluminum discharge elbow for specified 7100 EXM-family monitor assemblies. It is a replacement waterway component, not a complete monitor, nozzle or assembled repair kit.

Choose this elbow by the monitor assembly and exact part number, not by appearance or a general pipe-size comparison. During service, confirm the mating components and the seals and fasteners needed for the repair; those items require their own selection.

Technical specifications

Specification	Details
Manufacturer	Elkhart Brass
Part number	28146001
Component	Discharge elbow
Material	Aluminum
Family designation	7100 EXM

Applications and related parts

Assembly	Selection guidance
7100 SDX2	02007101SD assembly, discharge elbow item 2
7100 HDX2	02007101HD assembly, discharge elbow item 2
Related parts	Inlet body 16257001 is a separate waterway component

Before ordering

Check	What to confirm
Model	Confirm the monitor model, assembly configuration and exact replacement part number.
Quantity	Confirm the number needed for the repair; do not assume an assembly quantity is a packaged kit.
Service	Isolate electrical power and water supply, release trapped pressure and follow the monitor service procedure before disassembly.
