Harness Y - Splitter, CANbus, EXM2, Elkhart 24196000 - UnitedBuilt Equipment

Elkhart Brass 24196000 CAN Network Y-Splitter

UGC 0012631
par Elkhart Brass
Disponibilité:
2 en stock | En stock
Économisez 19% Économisez 19%
$137.00
$137.00 - $137.00
$137.00
$111.00
$111.00 - $111.00
$111.00

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The Elkhart Brass 24196000 CAN network Y-splitter provides a branch connection for compatible Elkhart EXM2 and APEX control networks. Use it where the system wiring arrangement calls for an additional CAN connection between the network ends.

This splitter is not the 24197000 CAN termination plug. Extension harnesses, termination components, controllers and actuators are separate selections. Match the connection arrangement before ordering rather than treating every three-pin accessory as interchangeable.

Network connections

Feature Selection guidance
Branch connection Connects a compatible CAN component to the main communication line.
System planning Allows selection of the splitter separately from extension harnesses and termination components.

Technical specifications

Specification Details
Manufacturer Elkhart Brass
Part number 24196000
Component CAN network Y-splitter
Applications Specified EXM2, APEX and BrushHawk 8495 CAN network arrangements

Before ordering

Check What to confirm
Network Match the controller, monitor or actuator and its wiring diagram.
Termination An EXM2 CAN network requires two end termination points; the splitter does not replace the required termination plug.
Branches For the EXM2 arrangement, keep the branch from the main CAN line to a component no longer than 3 feet.
Other parts Select any required CAN extension harness and 24197000 termination plug separately.
Install Disconnect electrical power before connecting or disconnecting components; follow the system wiring and configuration instructions.

Need help confirming a replacement part? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your equipment model, existing part number and photos.
