O-Ring, AS-568-151, 2.987 x 0.103 in., Elkhart 57490000

Name: O-Ring, AS-568-151, 2.987 x 0.103 in., Elkhart 57490000
Brand: Elkhart Brass
SKU: 0012623
Price: 10.5 USD
Availability: InStock

UGC 0012623

par Elkhart Brass

Disponibilité:

1 en stock | En stock

Économisez 19%

$13.00

$13.00 - $13.00

$13.00

$10.50

$10.50 - $10.50

$10.50

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

La description

The Elkhart Brass 57490000 O-ring is a replacement sealing component for 7000-EHD master-stream nozzles. Its AS-568-151 size measures 2.987 inches inside diameter with a 0.103-inch cross-section, helping you distinguish it from other O-rings used in the same equipment.

Choose this part when the nozzle service parts list calls for 57490000. It is an individual O-ring component, not a complete nozzle or a multi-piece seal kit; match the exact part number and installed nozzle model before ordering.

Replace the correct nozzle seal

Servicing the specified O-ring lets you address that sealing component without ordering a complete nozzle. Check the surrounding sealing surfaces and the other seals during service so a damaged mating part is not overlooked.

Feature	Benefit
Exact replacement part number	Helps avoid substituting a similar-looking seal from another position in the nozzle.
Defined O-ring dimensions	Supports comparison with the specified replacement size when planning maintenance.

Technical specifications and fitment

Specification	Detail
Manufacturer	Elkhart Brass
Part number	57490000
Size designation	AS-568-151
Inside diameter	2.987 inches
Cross-section	0.103 inch
Nozzle application	7000-EHD
Product supplied	O-ring component; not a nozzle or full seal kit

Before ordering

Do not select a substitute by approximate diameter alone. Confirm the service part number for your equipment and follow its installation and lubrication instructions. Inspect the assembled nozzle and verify correct operation before returning it to service.

Check	What to confirm
Nozzle identification	Match 7000-EHD and the specified 57490000 service part.
Seal position	Check the parts list: other O-rings in the same nozzle can have different dimensions.
Service requirements	Confirm the correct lubricant and installation procedure for the nozzle.
Additional parts	Order other seals or damaged components separately as needed.

Need help selecting the correct part? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your nozzle model, existing part number and photos.
