Air Actuator, Double Acting 354 IN/LB @ 80 PSI with Linkage Kit for Victaulic 3" Vic - 300 761 Valve, VSI C - DA063 - UnitedBuilt Equipment

Air Actuator, Double Acting 354 IN/LB @ 80 PSI with Linkage Kit for Victaulic 3" Vic-300 761 Valve, VSI C-DA063

UGC 0012151
par UnitedBuilt Equipment
Disponibilité:
5 en stock | En stock
$0.00 - $0.00
$0.00
$560.00
$560.00 - $560.00
$560.00

Images du produit

Les images sont uniquement à titre de représentation et peuvent différer du produit réel.

The VSI C-DA063 is a double-acting rack-and-pinion pneumatic actuator supplied with a linkage kit for a compatible 3 in. Victaulic Vic-300 MasterSeal Series 761 butterfly valve. It delivers 354 in-lb of output torque at 80 PSI for quarter-turn valve operation.

Series C operation supplies air to Port A for counterclockwise rotation and Port B for clockwise rotation. An aluminum-alloy body, cast-aluminum end caps, alloy-steel pinion, NBR seals, and a G1/4 NAMUR air connection support reliable pneumatic valve-control assemblies.

VSI specifies a 40 PSI minimum air supply and recommends 80-100 PSI. Confirm valve size, torque requirements, linkage alignment, and available air pressure before installation.

Key Features

Feature Details
3-Inch Victaulic 761 Configuration Includes linkage for a compatible 3 in. Vic-300 MasterSeal Series 761 valve
Double-Acting Pneumatic Operation Compressed air powers both counterclockwise and clockwise rotation
354 in-lb at 80 PSI Provides published output torque for compatible quarter-turn valve operation
Series C Construction Aluminum body and end caps, alloy-steel pinion, and NBR seals
NAMUR Air Connection G1/4 interface supports compatible pneumatic controls
Water Truck Valve Control Suitable for compatible pneumatic butterfly valves in water-truck plumbing

Specifications

Attribute Details
Brand Valve Solutions, Inc. (VSI)
Actuator Model C-DA063
UnitedBuilt SKU 0012151
Actuator Series Series C
Actuator Type Double-Acting Rack-and-Pinion Pneumatic
Valve Compatibility 3 in. Victaulic Vic-300 MasterSeal Series 761
Included Configuration Actuator with Linkage Kit
Output Torque at 58 PSI 257 in-lb
Output Torque at 73 PSI 319 in-lb
Output Torque at 80 PSI 354 in-lb
Output Torque at 87 PSI 389 in-lb
Output Torque at 102 PSI 451 in-lb
Air Supply 40 PSI Minimum / 80-100 PSI Recommended
Air Connection G1/4 NAMUR
Air Consumption 12.81 cu. in. Opening / 14.04 cu. in. Closing
Body Material Aluminum Alloy 6005-T5
End Cap Material Cast Aluminum ADC12
Pinion Material Alloy Steel
Seal Material NBR
Actuator Weight 4.41 lb (linkage not included in published weight)
Rotation Port A: CCW / Port B: CW

Applications

Application Use Case
3-Inch Victaulic Butterfly Valve Control Pneumatic actuation for a compatible Series 761 valve
Water Truck Plumbing Controls compatible 3 in. butterfly valves in water-distribution systems
Spray and Discharge Systems Supports remote pneumatic valve operation where torque requirements match
Industrial Grooved Piping Actuation kit for a compatible Victaulic valve assembly
