The Camozzi MC104-R00TF air pressure regulator is a modular Series MC regulator for controlling compressed-air pressure in pneumatic systems. It features 1/4" NPTF ports, a self-relieving diaphragm design, and an adjustable outlet pressure range of 7.25-145 PSI.
This regulator is built for air treatment assemblies, pneumatic controls, valve circuits, and equipment air systems where consistent downstream air pressure is important. It can be used in compatible water truck air systems, including pneumatic control circuits for valves, PTO controls, and other compressed-air components used on construction and dust control trucks.
Use this regulator with compatible compressed-air systems only. Always confirm port size, pressure range, flow requirements, gauge port requirements, mounting style, and system compatibility before installation.
Key Features
| Feature |
Details |
| Modular Series MC Regulator |
Fits compatible Camozzi MC air treatment assemblies |
| 1/4" NPTF Ports |
Connects to compatible 1/4" female pipe thread air lines and fittings |
| Adjustable Outlet Pressure |
Regulates downstream air pressure from 7.25-145 PSI |
| Self-Relieving Design |
Helps vent excess downstream pressure during adjustment |
| Lockable Adjustment Knob |
Pull-up / push-down knob helps prevent unwanted setting changes |
| Gauge Port Included |
1/8" NPTF gauge ports allow pressure gauge installation |
| Panel Mount Capable |
Supports in-line, wall, or panel mounting on compatible equipment |
| Water Truck Air System Use |
Suitable for compatible pneumatic control circuits on water truck equipment |
Specifications
| Attribute |
Details |
| Brand |
Camozzi |
| Part Number |
MC104-R00TF |
| Series |
MC Series |
| Product Type |
Air Pressure Regulator |
| Regulator Type |
Modular pneumatic pressure regulator |
| Port Size |
1/4" NPTF |
| Gauge Port |
1/8" NPTF |
| Inlet Pressure |
0-232 PSI |
| Outlet Pressure Range |
7.25-145 PSI |
| Nominal Flow |
70 SCFM |
| Diaphragm Type |
Self-relieving |
| Mounting Style |
In-line, wall, or panel mounting |
| Operating Temperature |
32°F to 122°F at 145 PSI |
| Included Hardware |
Bulkhead mounting nut; gauge port plug |
| Primary Media |
Compressed air |
| Water Compatibility |
Not for water service; use with compatible compressed-air systems only |
Applications
| Application |
Use Case |
| Water Truck Air Systems |
Regulate air pressure for compatible pneumatic control circuits |
| PTO Air Controls |
Support consistent air pressure for compatible air-operated PTO controls |
| Air-Operated Valve Circuits |
Regulate supply pressure to compatible pneumatic valve systems |
| Pneumatic Control Panels |
Control downstream pressure in compact air treatment assemblies |
| Dust Control Trucks |
Service compressed-air circuits on construction water trucks |
| Industrial Air Systems |
Maintain regulated pressure for general pneumatic equipment |
| Equipment Repair & Upfits |
Replace worn or damaged regulators when specifications match |
