Sleeve, Shaft 1 - 1/2" ID x 1 - 7/8" OD, B4E, Berkeley S05974 - UnitedBuilt Equipment

Manchon, arbre 1-1/2" ID x 1-7/8" OD, B4E, Berkeley S05974

UGC 0004200
par Berkeley
Disponibilité:
2 en stock | En stock
Économisez 30% Économisez 30%
$549.00
$549.00 - $549.00
$549.00
$384.00
$384.00 - $384.00
$384.00

Product Images

Images are for representation only and may differ from the actual product.

Questions about this product?

The Berkeley S05974L shaft sleeve is a replacement sleeve measuring 1-1/2-inch ID x 1-7/8-inch OD x 3-1/2-inch long. It fits the shaft-service arrangements that specify this exact sleeve.

The sleeve is a separate component from the shaft, bearings and seal. Check the complete pump configuration and existing sleeve dimensions together, and match the full S05974L part number, including the suffix.

Renew the sleeve while retaining a serviceable shaft

The replaceable sleeve allows this part of the shaft arrangement to be serviced independently. Inspect the sleeve seating area and the seal or packing contact surfaces during repair so all affected components can be selected together.

Feature Benefit
Separate shaft sleeve Replace the sleeve without assuming that a complete shaft kit is needed.
Three stated dimensions Check the shaft fit, outside diameter and installed length.
Exact S05974L identification Match the suffix as well as the base part number when selecting the replacement.

Technical specifications

Specification Details
Manufacturer Berkeley
Manufacturer part number S05974L
Inside diameter 1-1/2 in.
Outside diameter 1-7/8 in.
Length 3-1/2 in.
Item supplied Shaft sleeve

Compatibility and components

Component or application Selection guidance
B60659 shaft replacement kit S05974L is the sleeve for the B ERB CW/CCW kit.
B07596 / B07597 shaft kits S05974L fits these CW and CCW replacement-shaft kits.
Seal or packing parts Separate components; confirm their compatibility with the exact pump arrangement.

Before ordering

Check What to confirm
Part number Confirm the full S05974L identifier.
Dimensions Match all three sleeve dimensions and the shaft arrangement.
Installation Inspect mating surfaces and use the pump-specific service instructions with the drive isolated.

Need help selecting the correct replacement part? Contact UnitedBuilt through online chat, email parts@unitedbuilt.com, or call 602-253-7750 with your pump model, existing part number, and photos.
